FieldWiz

The new FieldWiz is the smallest and lightest sensor available on the market with the highest level of integration.

GNSS, IMU and heart rate monitoring are integrated in just 35 g, FieldWiz allows you to measure your team's performance and collect reliable data during matches and trainings to help you make decisions to improve your strategy and win your game. State-of-the-art GNSS technology with 18 Hz sampling rate  offers the precision needed to monitor player performance, set goals and encourage healthy competition within the team. Fieldwiz meets the international standard required by FIFA for its electronic performance and the quality of the tracking system.

Benefits - Why using Tracking devices?

Get a clear view of what happens on the pitch:

• Manage activities to achieve the most of it
• Set goals and track progress
• Monitor the load, prevent injuries
• Rehabilitate safely
• Reinforce intuition and create predictability
• Communicate effectively
• Contextualize data with video integration

Fieldwiz is a complete system and thanks to the easy to use Dock Station one can manage multiple devices all at once:

• the only docking station on the market that allows you to manage up to 30 devices,
• Integrated screen
• Charges all  the devices
• Sync devices for fast data download
• Recommended when managing more than 10 athletes per session
• Facilitate team management
• It allows you to easily transport all the devices in one console

The advanced platform allows users to easily load, store, visualize and analyse their performance data.

• No installation required
• Updates automatically deployed.
• Thresholds and parameters easily customizable.
• User-friendly interface
• Personalized user experience
• Esports

Technical Features

FieldWiz is a position, motion and heart-rate sensor.

It includes:

• GNSS sensor (position sensor)
• Concurrent reception of GPS, Galileo, GLONASS, BeiDou
• 167 dBm navigation sensitivity
• 72 channels
• Up to 18Hz update rate
• 30 cm relative position accuracy
• Speed accuracy of 0.05m/s
• IMU (inertial motion unit) :
• o3-axis accelerometer
• Up to 250Hz sampling frequency (configurable)
• 16-bits output data
• 3-axis gyroscope
• Up to 250Hz sampling frequency (configurable)
• 16-bits output data
• 3-axis magnetometer
• Up to 250Hz sampling frequency (configurable)
• 16-bits output data
• ECG sensor (electrocardiogram)
• Heart rate computation
• Internal memory allowing up to 350 hours of data recording Rechargeable battery
• Autonomy of 6 hours
• Full recharge time : 1 hour
• Dimensions : 65mm x 35mm x 15mm Weight : 35g Waterproof (sweat-proof, splash-proof) Functional temperature : -20°C to 55°C
